In pharmaceutical manufacturing, biotechnology research, and chemical processing, handling highly potent compounds requires strict containment measures to protect operators, products, and the surrounding environment. A modern Containment Isolator provides an enclosed and controlled workspace that significantly reduces exposure risks while ensuring process accuracy and product quality.
Tailin, a provider of advanced containment and cleanroom solutions, offers a range of containment isolators specifically designed for weighing, sampling, freeze-drying, capping, and multifunctional laboratory operations. These systems combine OEB5-level protection, high-efficiency filtration, and flexible process integration to meet the demanding requirements of modern pharmaceutical and research facilities.
Tailin Containment Isolator for Weighing and Sampling
Accurate weighing and safe sampling are critical steps in the handling of highly potent active ingredients. The Tailin Containment Isolator for Weighing and Sampling is engineered to provide exceptional containment performance while maintaining precise measurement capabilities.
Standard Configurations
This system is equipped with:
- 8Y one-piece gloves
- Continuous liner system
- Waterproof socket
- LED lighting
- 316L stainless steel waste liquid container
- Electronic scale
- H14 PUSH-PUSH HEPA filtration system
- EBM blower
- Siemens touchscreen and PLC control platform
Key Features
The weighing and sampling isolator offers:
- Compliance with OEB5 personal protection requirements
- Successful third-party containment testing
- Occupational Exposure Limit (OEL) below 0.05 μg/m³
- Installation within a general background environment while maintaining a static Class C internal environment
- Weighing precision levels of 1/10,000, 1/100,000, and 1/1,000,000
- Safe material transfer through a continuous liner system and Rapid Transfer Port (RTP)
- SS316L mobile liquid waste container for convenient handling of highly potent liquid waste
These capabilities make the Tailin Containment Isolator particularly suitable for pharmaceutical weighing rooms, R&D laboratories, and high-potency production areas.
Tailin Containment Isolator for Freeze-Drying, Weighing and Capping
Many pharmaceutical processes require multiple operations to be completed under strict containment conditions. To address this need, Tailin has developed an integrated containment isolator that combines freeze-drying, weighing, and capping functions within a single controlled environment.
Standard Configurations
The system includes:
- 8Y one-piece gloves
- Explosion-proof socket
- Explosion-proof computer
- Explosion-proof LED lighting
- Continuous liner system
- H14 PUSH-PUSH HEPA filtration
- Explosion-proof blower
Key Features
The Tailin integrated containment solution provides:
- Compliance with OEB5 containment design requirements
- Occupational Exposure Limit (OEL) below 0.1 μg/m³
- Fully explosion-proof construction meeting EXd II BT4 and ATEX standards
- Integration of:
- Freeze dryer chamber
- Manifold shelf
- Rotary evaporator
- Electronic scale
- Capping machine
- Installation in laboratory environments using room-supplied fresh air
- Customized designs tailored to facility layouts and available space
This integrated approach reduces material handling steps, improves workflow efficiency, and enhances operator protection.
Tailin Multifunctional Negative Pressure Containment Isolator
For laboratories and pilot facilities that require maximum flexibility, the Tailin Multifunctional Negative Pressure Containment Isolator offers a versatile platform capable of accommodating numerous processing operations within a single containment environment.
Standard Configurations
The system features:
- 8Y one-piece gloves
- Explosion-proof socket
- Continuous liner system
- Explosion-proof LED lighting
- Explosion-proof blower
- H14 PUSH-PUSH HEPA filtration
- Explosion-proof computer
Key Features
This advanced Tailin Containment Isolator provides:
- Compliance with OEB5 design requirements
- Ultra-low occupational exposure limit of OEL < 0.01 μg/m³
- Integration of multiple process technologies, including:
- Weighing
- Dispensing
- Capping
- Stirring
- Ultrasonic processing
- Feeding systems
- Extraction equipment
- Rotary evaporation
- Column chromatography
- Centrifugation
- Installation in standard laboratory rooms with fresh-air supply
- Fully customized configurations based on process requirements and site conditions
Its negative-pressure design ensures hazardous particles remain contained, even during complex operations involving highly potent compounds.
Why Tailin Containment Isolator Solutions Stand Out
OEB5-Level Personnel Protection
All three containment solutions are designed to meet stringent OEB5 containment requirements, making them suitable for handling highly potent pharmaceutical ingredients and hazardous compounds.
Advanced HEPA Filtration
Each Tailin Containment Isolator utilizes H14 PUSH-PUSH HEPA filtration, helping maintain clean operating conditions while preventing the release of airborne contaminants.
Safe Material Transfer
The incorporation of continuous liner systems and RTP technology minimizes exposure during material loading and unloading processes.
Explosion-Proof Options
For solvent-based processes and hazardous environments, Tailin provides explosion-proof components that comply with internationally recognized safety standards, including ATEX and EXd II BT4 requirements.
Flexible Customization
Every Tailin Containment Isolator can be customized to fit specific process requirements, equipment integration needs, and facility layouts, providing a tailored containment solution for each application.
As pharmaceutical and chemical industries continue to work with increasingly potent compounds, the need for reliable containment solutions continues to grow. Tailin Containment Isolator systems provide a comprehensive solution for weighing, sampling, freeze-drying, capping, dispensing, extraction, and other critical operations.
Featuring OEB5-compliant designs, H14 HEPA filtration, continuous liner transfer systems, explosion-proof configurations, and occupational exposure limits ranging from 0.1 μg/m³ to 0.01 μg/m³, Tailin containment technologies help organizations achieve safer operations, improved compliance, and greater process efficiency while protecting both personnel and product quality.
