Dry Fogger

Used for bio-decontamination in enclosed spaces

Introduction

Features

Specifications

Applications

Inquiry

The Dry Fogger FHP3 utilizes a micron-level atomization system to convert the liquid solution into fine micron-sized particles, forming a dry mist. In this state, H2O2 is rapidly dispersed into the environment under high-pressure, high-speed airflow, providing broad- spectrum and highly effective disinfection for air and surfaces.

Broad-spectrum disinfection: effective to bacteria (vegetative and spores, viruses and fungi)

The H2O2 concentration is ≤8% with good compatibility

PLC control, sound and light alarm

Features

Highly efficient and broad-spectrum sterilization, capable of eliminating various bacteria, viruses, fungi, and spores.
No residue, secondary pollution, or harmful substances after bio-decontamination.
H₂O₂solution concentration 8%, ensuring excellent material compatibility.
Ultra-fine atomized particles with uniform diffusion.
Light weight, flexible, and easy to move and carry.
Intelligent control system with one-button setup and one-button start.
Quick and convenient dosing.
Remote wireless control for enhanced operational safety.
Delay start and appointment start function.
Equipped with audio-visual alarm function.

Specifications

Max. Sterilization Space: 150m³	Sterilant: 8% food-grade H2O2 solution
Solution Tank Capacity: 500mL/1L	Injection Rate: Approximately 25 g/min
Delay Start: 30s(Adjustable)	Operation Mode: 3-inch color touchscreen
Appointment Start: Support	Audio-Visual Alarm: Equipped with Tri-Color LED light and buzzer
WIFI Control: Equipped with a remote control (control range: 50–300 meters in open areas)	Weight: 9kg
Operating Power: 300W	Power Supply: AC 220V±22V, Frequency 50Hz ±1Hz (Standard Version), DC 24V(Battery Version)
Dimensions(mm): 380x260x380 (W×D×H)	Model: Standard version / battery version

Applications

Widely used for bio- decontamination in enclosed spaces such as biosatety laboratories, research institutes, pharmaceutical companies, animal facilities, hospitals, and ambulances.
